Meraki MV52 8.4 Megapixel Outdoor 4K Network Camera - Color - Bullet

Part No. MV52-HW

by Cisco Systems, Inc

Meraki MV52 8.4 Megapixel Outdoor 4K Network Camera - Color - Bullet

164.04 ft (50 m) Infrared Night Vision - H.264 - 3840 x 2160 - 12 mm (0.47")- 40 mm (1.57") Varifocal Lens - 3.3x Optical - 30 fps - CMOS - Wall Mount, Ceiling Mount, Junction Box Mount, Pole Mount - IK10+ - IP67 - Vandal Resistant, Weather Proof

Part No. MV52-HW

by Cisco Systems, Inc

$2540.99
General Information
ManufacturerCisco Systems, Inc
Manufacturer Part NumberMV52-HW
Brand NameMeraki
Product ModelMV52
Product NameUltra-Long-Range Telephoto Bullet Camera
Marketing Information

The Meraki MV52, part of the MV smart camera family, brings physical security and advanced analytics together in a powerful, ultra-long-
range telephoto bullet camera. The MV52 extends visibility and safety to challenging environments where distance and detail matter.

MV52: security and intelligence

MV52 has an industry-leading processor, 1TB of high-endurance local storage, and browser-based cloud management and viewing. This
edge architecture minimizes physical infrastructure and software requirements, enabling faster, easier deployments and greater scalability.

With the ability to mount to walls, ceilings, or poles, and a 360-degree rotating flexible ball joint, MV52 lets you get the angle you need,
anywhere. Wireless functionality and a built-in power input option make it possible to install in even the most challenging environments
beyond the reach of normal Ethernet.

MV52 combines a 12°-37° field of view with 4K video resolution. This allows for high detail, even with long-distance deployments like
parking lots or perimeter monitoring. It's also useful for situations that require license plate capture or subject identification.

Using machine-learning-based computer vision, MV52 can do real-time object detection, classification, and tracking of people and vehicles
to increase safety and provide useful insights into activity. These smart cameras enable physical security and business intelligence, all in a
refreshingly simple package.

Product TypeNetwork Camera
Technical Information
Recording Formats4K
HD RecordingYes
Night VisionYes
Night Vision Distance164.04 ft (50 m)
Night Vision TypeInfrared
Display & Graphics
Image Sensor TypeCMOS
Color SupportedColor
Field of ViewHorizontal 12°-37°, Vertical 7°-22°
Effective Camera Resolution8.4 Megapixel
Video
Video FormatsH.264
Maximum Video Resolution3840 x 2160
Maximum Frame Rate30 fps
Lens
Lens TypeVarifocal
Minimum Focal Length12 mm (0.47")
Maximum Focal Length40 mm (1.57")
Lens IncludedYes
Minimum Aperturef/2.3
Maximum Aperturef/16
Optical Zoom3.3x
Exposure
Shortest Shutter Speed1/1000 Second
Longest Shutter Speed1/30 Second
Network & Communication
Connectivity TechnologyWired
Remote ManagementYes
Interfaces/Ports
Network (RJ-45)Yes
Power Description
Input Voltage12 V DC
Physical Characteristics
Mount Type
  • Wall Mount
  • Ceiling Mount
  • Junction Box Mount
  • Pole Mount
Form FactorBullet
Durability
  • Vandal Resistant
  • Weather Proof
Length5.71" (145 mm)
Diameter3.54" (90 mm)
Weight (Approximate)3.31 lb (1500 g)
Environmental Conditions
Minimum Operating Temperature-40°F (-40°C)
Maximum Operating Temperature122°F (50°C)
Miscellaneous
Features
  • Built-in Infrared Illuminator
  • Microphone In
  • Built-in IR LED
Indoor/OutdoorOutdoor
Package Contents
  • Ultra-Long-Range Telephoto Bullet Camera
  • Quick Start & Installation Guide
  • MV Camera Hardware
  • Wall Mounting Kit
Impact Protection RatingIK10+
Ingress Protection RatingIP67
ConditionNo
UPC0810979017646
Warranty
Limited Warranty5 Year
