APC by Schneider Electric NetShelter 9000 24-Outlets PDU

Part No. APDU9961

by Schneider Electric SA

APC by Schneider Electric NetShelter 9000 24-Outlets PDU

Switched - NEMA L21-20P - 3 x IEC 60320 C19/C21, 21 x IEC 60320 C13/C15 - 208 V - Network (RJ-45) - 6 ft (1.83 m) Cord Length - 0U - Vertical - Rack-mountable - Tower

Part No. APDU9961

by Schneider Electric SA

$2107.99
General Information
ManufacturerSchneider Electric SA
Manufacturer Part NumberAPDU9961
Brand NameAPC by Schneider Electric
Product Series9000
Product NameNetShelter 9000 24-Outlets PDU
Marketing Information

It is a switched rack PDU with a maximum current capacity of 20A and an input voltage of 208V. It includes 21 C13 and C15 outlets and 3 C19 and C21 outlets, connected via a NEMA L21-20P input connection. The PDU has a ZeroU form factor and a cord length of 6 feet (1.8 meters). It supports remote monitoring and user-defined alarms, with outlet-level on or off switching capabilities. The unit is UL Listed and CSA certified, ensuring high safety and performance standards.

Product TypePDU
Technical Information
PDU TypeSwitched
PhaseThree Phase
Plug/Connector TypeNEMA L21-20P
Receptacle Type
  • IEC 60320 C19/C21
  • IEC 60320 C13/C15
Receptacle Detail
  • 3 x IEC 60320 C19/C21
  • 21 x IEC 60320 C13/C15
Power Description
Input Voltage208 V
Output Voltage208 V AC
Power Rating (VA)5.70 kVA
Power Rating (Watt)5.80 kW
Input Current20 A
Management
Management
  • Web
  • SNMP
  • Telnet
Interfaces/Ports
Network (RJ-45)Yes
Physical Characteristics
Mounting OrientationVertical
Mounting PreferenceNo Preference
Mount TypeRack-mountable
PlacementSide
Form FactorTower
Rack Height0U
Cord Length6 ft (1.83 m)
Height70.55" (1792 mm)
Width2.17" (55 mm)
Depth1.81" (46 mm)
Weight (Approximate)15.23 lb (6908.21 g)
Miscellaneous
For Country/RegionUnited States
Package Contents
  • NetShelter 9000 24-Outlets PDU
  • Installation guide
  • Rack mounting brackets
  • Safety guide
  • Certifications & StandardscUL Listed|FCC part 15 class A
    Product Take Back ProgramNo
    REACH free of SVHCNo
    Mercury FreeYes
    RoHS Exemption Informationhttps://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=APDU9961_ROHS_DECLARATION&p_FileName=APDU9961KIT_ROHS_DECLARATION_US.pdf
    REACH Declaration URLhttps://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=557330937&lang=en-us
    EU RoHS Declaration URLhttps://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=557330937&lang=en-us
    Environmental Profile Availabilityhttps://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612033_EN
    End of Life Manual Availabilityhttps://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612033_EN
    WEEE StatementThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Country of OriginIndia
    Environmentally FriendlyYes
    Environmental ComplianceRestriction of Hazardous Substances (RoHS)
    ConditionNo
    UPC0731304356318
    Warranty
    Limited Warranty3 Year
    Additional Warranty Information3 years repair or replace
