APC by Schneider Electric NetShelter 9000 24-Outlet PDU
Switched - NEMA L6-30P - 21 x IEC 60320 C13/C15, 3 x IEC 60320 C19/C21 - 200 V, 208 V - Overload Protection - Network (RJ-45) - 10 ft (3.05 m) Cord Length - 0U - Vertical - Rack-mountable - Tower
$1882.99
In Stock Availability
- All Locations: (20+)
- Toronto, ON (22+)
- Vancouver, BC (1+)
General Information
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | APDU9941 |
| Brand Name | APC by Schneider Electric |
| Product Series | 9000 |
| Product Name | NetShelter 9000 24-Outlet PDU |
| Marketing Information | The APC Switched Rack PDU distributes reliable power within a rack through a single input and multiple output receptacles The APDU9941 offers advanced load management combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management The 0U PDU includes a NEMA L6-30P input plug with 3 05m (10 ft) cord, (21) IEC 60320 C13/C15 and (3) IEC 60320 C19/C21 hybrid outlet receptacles The hybrid outlets allow 60°C operating temperature at full load, are compatible with standard C14 and C20 power cords, and are future-proofed for new C16 and C21 power cords required for higher temperature rated devices The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy The rack PDU integrates with EcoStruxure IT through Network Management Card and can be accessed, configured, and managed remotely via Web, SNMP and Command Line Interface Color user-interactive LCD interface details current, real power, voltage, and energy measurements for local user access The outlet level control allows power on/off functionality for power recycling/reboot of remote equipment and restricts unauthorized use of individual outlets The Switched Rack PDU includes a temperature/humidity sensor port, locking IEC outlets when used with locking power cords, low-profile circuit breakers and USB port for local Firmware updates The rack PDU supports daisy-chain of up to 32 PDUs on a single IP address, thereby reducing networking cost The rack PDU comes with a standard three-year warranty |
| Product Type | PDU |
Technical Information
| PDU Type | Switched |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type |
|
| Receptacle Detail |
|
| Protection Type | Overload Protection |
Power Description
| Input Voltage |
|
| Input Voltage Range | 200 V AC - 240 V AC |
| Output Voltage |
|
| Power Rating (VA) | 4.99 kVA |
| Power Rating (Watt) | 5 kW |
| Input Current | 30 A |
Management
| Management |
|
Interfaces/Ports
| Network (RJ-45) | Yes |
Physical Characteristics
| Mounting Orientation | Vertical |
| Mounting Preference | No Preference |
| Mount Type | Rack-mountable |
| Placement | Side |
| Form Factor | Tower |
| Rack Height | 0U |
| Cord Length | 10 ft (3.05 m) |
| Height | 72.01" (1829 mm) |
| Width | 2.17" (55 mm) |
| Depth | 1.81" (46 mm) |
| Weight (Approximate) | 18.74 lb (8500.32 g) |
Miscellaneous
| For Country/Region | United States |
| Package Contents | |
| Certifications & Standards | cUL Listed|FCC part 15 class A|PSE |
| Product Take Back Program | No |
| REACH free of SVHC | No |
| Mercury Free | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=APDU9941_ROHS_DECLARATION&p_FileName=APDU9941KIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=557330941&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=557330941&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612033_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612033_EN |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Country of Origin | India |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Condition | No |
| UPC | 0731304356264 |
Warranty
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3 years repair or replace |
