Supermicro SuperServer F619P2-RT Server Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support

Intel C621 Chip - 1.50 TB DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support - 12 Total Memory Slots - Serial ATA/600 RAID Supported Controller - AST2500 Graphic(s) - 14 SATA Interface(s) - Processor Support (Xeon) - Ethernet - 2 USB 3.0 Port(s) - 4 x 2.20 kW

Part No. SYS-F619P2-RT

by Supermicro Computer, Inc

$16959.99

Specifications
Options & Accessories (5)

General Information

Manufacturer	Supermicro Computer, Inc
Manufacturer Part Number	SYS-F619P2-RT
Brand Name	Supermicro
Product Line	SuperServer
Product Model	F619P2-RT
Product Name	SuperServer F619P2-RT (Black)
Marketing Information	Scalable Processors + C620 based FatTwin™ SuperServer / Socket P - LGA 3647 / DP & UP Xeon 4U Xeon® Scalable Processors The FatTwin is available in high-density 8 / 4 / 2 hot-plug system node configurations with a choice of memory capacities, hard disk drives, power supplies, front or rear I/O, PCI and networking options and more. Its high efficiency, highly effective shared cooling architecture allows the FatTwin to operate in high-temperature, free-air cooled environments up to 47°C, providing considerable cost savings and improved TCO. Versatile configurations allow the FatTwin to be optimized for many different environments including Data Center, Cloud Computing, and HPC; Engineering, Research, and GPU projects; File and Storage Server deployments; and General Server and Enterprise Server applications.
Product Type	Server Barebone System

Processor

Number of Nodes	8
Number of Processors Supported	2
Processor Socket	Socket P LGA-3647
Processor Supported	Xeon
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C621

Memory

Maximum Memory Supported	1.50 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Total Number of Memory Slots	12

Controllers

Controller Type	Serial ATA/600
RAID Supported	Yes

Display & Graphics

Graphics Controller Model	AST2500

Network & Communication

Ethernet Technology	Ethernet

I/O Expansions

Number of Total Expansion Bays	6
Total Number of Expansion Slots	2
Number of PCI Express x16 Slots	2

Interfaces/Ports

Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of SATA Interfaces	14

Power Description

Input Voltage	120 V AC 230 V AC
Number of Power Supplies Installed	4
Maximum Power Supply Wattage	2.20 kW

Physical Characteristics

Color Family	Black
Product Color	Black
Form Factor	Rack-mountable
Rack Height	4U
Height	6.96" (176.78 mm)
Width	17.63" (447.80 mm)
Depth	29" (736.60 mm)
Weight (Approximate)	150 lb (68038.86 g)
