Datalogic PowerScan PBT9500 Handheld Barcode Scanner

Part No. PBT9500-RB

by Datalogic S.p.A

Datalogic PowerScan PBT9500 Handheld Barcode Scanner

Wireless Connectivity - 1D, 2D - Imager - Omni-directional - Bluetooth - Yellow, Black

Part No. PBT9500-RB

by Datalogic S.p.A

$512.99
General Information
ManufacturerDatalogic S.p.A
Manufacturer Part NumberPBT9500-RB
Brand NameDatalogic
Product LinePowerScan
Product ModelPBT9500
Product NamePowerScan PBT9500 Handheld Barcode Scanner
Marketing Information

The PowerScan 9500 family of imagers is targeted to be the most suitable solution for all applications in warehouses, transportation & logistics and manufacturing. The omnidirectional reading capability combined with the snappiness and the depth-of-field features allow the PowerScan 9500 imagers to be faster and therefore, a preferred solution over standard laser scanners.

The PowerScan PBT9500 area imager is a mobile scanner based on Bluetooth® wireless technology. It includes all of the scanning features associated with the PowerScan 9500 family and provides the freedom of mobility to move around a warehouse without the entanglement of cables.

Product TypeBarcode Scanner
Technical Information
Connectivity TechnologyWireless
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported1D / Linear Codes:
  • Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes
2D Codes:
  • Aztec Code
  • China Han Xin Code
  • Data Matrix
  • MaxiCode
  • Micro QR Code
  • QR Code
Postal Codes:
  • Australian Post
  • China Post
  • IMB
  • Japanese Post
  • KIX Post
  • Planet Code
  • Portuguese Post
  • Postnet
  • Royal Mail Code (RM4SCC)
  • Swedish Post
Stacked Codes:
  • EAN/JAN Composites
  • GS1 DataBar Composites
  • GS1 DataBar Expanded Stacked
  • GS1 DataBar Stacked
  • GS1 DataBar Stacked Omnidirectional
  • MacroPDF
  • MicroPDF417
  • PDF417
  • UPC A/E Composites
Image Sensor TypeImager
Maximum Scan Resolution7.5 mil (0.190 mm)
Depth of Field
  • 6cm - 17cm@4mil
  • 9cm - 12cm@7.5mil - Data Matrix
  • 4cm - 18cm@10mil - Data Matrix
  • 2cm - 25cm@10mil - PDF417
  • 4cm - 45cm@13mil
  • 4cm - 55cm@20mil
  • 4cm - 85cm@40mil
Scan PatternOmni-directional
Network & Communication
BluetoothYes
Power Description
Power SourceBattery
Battery Information
Battery ChemistryLithium Ion (Li-Ion)
Maximum Number of Scans per Full Charge30000
Physical Characteristics
Form FactorHandheld
Product Color
  • Yellow
  • Black
Weight (Approximate)13.40 oz (380 g)
Miscellaneous
Additional Information

USB Cable separate

COOSK
ConditionNo
connector cables (15)

Part No. CAB-438

Datalogic Straight Cable - Type A USB

Part No. CAB-471

Datalogic DCE Coiled Cable - Female

cradles (2)
holders (3)

Part No. HLS-P080

Datalogic Universal Holster for Scanner

Part No. 7-0404

Datalogic Industrial Take-Up Reel

Part No. HLD-P080

Datalogic Desktop/Wall Holder for Scanner

power adapters (1)
power cords (5)

Part No. 6003-0923

Datalogic Standard Power Cord - United Kingdom
